Material: HT200-300
Specification: 750x1000-3000x8000mm or customize
Surface: T-slot
Hardness of the working surface: HB160-240 (HT200-300)
Surface treatment: hand-scraped or finish milling
Foundry process: resin sand casting
Painting: primer and face painting
Surface coating: pickling oil and plastic-lined or covered with anticorrosion paint
Precision grade: 1-3
Working temperature: (20±5)℃
Packaging: plywood box
No. | Width X Length（mm) | Precision Grade | ||
1 | 2 | 3 | ||
Flatness | ||||
1 | 1500X2000 | 20 | 40 | 80 |
2 | 1500X2500 | 22.5 | 45 | 90 |
3 | 1500X3000 | 25 | 50 | 100 |
4 | 2000X2000 | 22 | 44 | 88 |
5 | 2000X3000 | 27 | 53 | 106 |
6 | 2000X4000 | 32 | 64 | 127 |
7 | 2000X5000 | 37 | 75 | 150 |
8 | 2000X6000 | 43 | 86 | 172 |
9 | 2000X7000 | 49 | 97 | 194 |
10 | 2000X8000 | 54.5 | 109 | 218 |
11 | 2500X3000 | 28.5 | 57 | 114 |
12 | 2500X4000 | 33 | 67 | 133 |
13 | 2500X5000 | 39 | 77 | 154 |
14 | 2500X6000 | 88 | 176 | |
15 | 2500X7000 | 99 | 198 | |
16 | 2500X8000 | 110 | 221 | |
17 | 3000X3000 | 61 | 122 | |
18 | 3000X4000 | 70 | 140 | |
19 | 3000X5000 | 80 | 160 | |
20 | 3000X6000 | 90.5 | 181 | |
21 | 3000X7000 | 101 | 203 | |
22 | 3000X8000 | 112.5 | 225 | |
