Cast Iron Surface Plate for CMM

Next Product Inquire Now

    Material: HT200-300

    Specification: 750x1000-3000x8000mm or customize

    Surface: T-slot

    Hardness of the working surface: HB160-240 (HT200-300)

    Surface treatment: hand-scraped or finish milling

    Foundry process: resin sand casting

    Painting: primer and face painting

    Surface coating: pickling oil and plastic-lined or covered with anticorrosion paint

    Precision grade: 1-3

    Working temperature: (20±5)

    Packaging: plywood box


Specification:


No.

Width X Lengthmm)

Precision Grade

1

2

3

Flatness
  (μm)

1

1500X2000

20

40

80

2

1500X2500

22.5

45

90

3

1500X3000

25

50

100

4

2000X2000

22

44

88

5

2000X3000

27

53

106

6

2000X4000

32

64

127

7

2000X5000

37

75

150

8

2000X6000

43

86

172

9

2000X7000

49

97

194

10

2000X8000

54.5

109

218

11

2500X3000

28.5

57

114

12

2500X4000

33

67

133

13

2500X5000

39

77

154

14

2500X6000


88

176

15

2500X7000


99

198

16

2500X8000


110

221

17

3000X3000


61

122

18

3000X4000


70

140

19

3000X5000


80

160

20

3000X6000


90.5

181

21

3000X7000


101

203

22

3000X8000


112.5

225
